R 6,699.00
| Specification | Details |
|---|---|
| System | |
| Main Processor | Embedded processor |
| Operating System | Embedded Linux operating system |
| Button Type | Mechanical |
| Network Protocol | SIP, P2P, IPv4, FTP, UPnP, DNS, DDNS, RTSP, RTP, TCP, UDP |
| ROM | 4GB |
| RAM | 1GB |
| Basic | |
| Display Screen | 4.3 inch IPS screen |
| Resolution | 800 × 480 |
| Camera | 1/2.7″ 2MP CMOS HD, low illumination, white and IR illuminator |
| Angle of View | Horizontal: 113.79°, vertical: 61.5°, diagonal: 134.45° |
| Focal Length | 2.8mm |
| Aperture | F2.0 |
| WDR | 120dB |
| Noise Reduction | 3D noise reduction |
| Video Compression | H.264 |
| Video Resolution | Main stream: 720p, sub stream: 1080P |
| Frame Rate | Main stream (720P @ 25fps), sub stream (1080P @ 25fps), Main stream (720P @ 30fps), sub stream (1080P @ 30fps) |
| Video Bit Rate | 256Kbps – 2048Kbps |
| Light Compensation | Auto white light |
| Audio Compression | G.711u |
| Audio Input | 1 |
| Audio Output | Built-in speaker |
| Audio Mode | Full duplex communication |
| Audio Enhancement | Echo suppression, cancellation, digital noise reduction |
| Audio Bit Rate | 16KHz, 16Bit |
| Function | |
| Communication Mode | Full digital |
| Unlock Mode | Card, remote, password unlock |
| Card Type | IC card |
| Motion Detection | Video motion detection |
| Auto Snapshot | Yes |
| Leave Videos or Text Messages | Yes |
| Web Configuration | Yes |
| Performance | |
| Card Reading Distance | 1cm – 5cm |
| Issue Card Locally | Yes |
| Casing Material | Aluminium alloy |
| Capacity | |
| Card | 10,000 |
| Port | |
| RS-485 | 1 |
| Wiegand | 1 input port, 1 output port |
| Electric Lock | 1 |
| Alarm Input | 2 |
| Alarm Output | 2 |
| Power Output | 1 × 12V/100mA |
| Exit Button | 1 |
| Door Status Detection | 1 |
| Lock Control | 1, normally open by default |
| Network | 1 × RJ-45 10Mbps / 100Mbps self-adaptive |
| Alarm | |
| Tamper | Yes |
| General | |
| Password Unlock Mode | User password, public password, duress password |
| Colour | Silver |
| Power Supply Mode | DC 12V2A |
| Power Adapter | Optional |
| Installation | Surface mount and flush mount |
| Certification | CE FCC |
| Product Dimensions (H × W × D) | 389 mm × 145 mm × 41.9 mm (15.31″ × 5.71″ × 1.65″) |
| Protection Grade | IP65 |
| Operating Temperature | –30°C to +60°C (–22°F to +140°F) |
| Operating Humidity | 10%RH – 90%RH (non-condensing) |
| Operating Altitude | 86kPa – 106kPa |
| Power Consumption | ≤5W (standby), ≤18W (working) |
| Net Weight | 1.4 kg (3.09 lb) |
| Gross Weight | 1.68 kg (3.70 lb) |
